Description
The Waterproof RGB P10 LED Module Panels feature easy installation and high-resolution 10mm pixels, delivering crisp and clear animations for engaging visual displays. Designed for versatile use, they are ideal for license plate agencies, enhancing high point visibility. Built with a durable, waterproof P10 SMD LED design, these modules withstand outdoor conditions to ensure reliable performance. Additionally, the customizable animation function allows tailoring the LED digital signage to meet various project requirements.
| Color Parameters | |||
|---|---|---|---|
| LED sealed package | SMD | Single point pixel combination | 1R1G1B |
| Structure feature | light+driver | Cell board resolution | 32dot×16dot =512dot/pcs |
| Full colour | Red+Green+blue | Visible distance | 5-10M |
| Physical density | 10000点/m2 | Application | Ooutdoor |
| Physical point spacing | 10mm | Working time | 10,000 hours |
| Glowing point color | 1R1G1B | Service life | 75,000 ~100,000 hours |
| Driving way | Constant current | Power load | 5V/40A |
| Scanning way | 1/8 | Working voltage | 220V±10% |
| Cell board size | 320mm×160mm | Input voltage | 4.8~5.5V |
| White balanced brightness | ≥4500cd/m2 | Average power consumption | 250W/m2 |
| Module data interface | HUB-08 | Max power consumption | ≤500W/m2 |
| Operating temperature | -10℃~+60℃ | Planeness | gaps between modules |
| Relative humidity | 10%~95%RH | Cell board weight | 319.8g |
