A tough, high-flex test lead that connects securely from your 4 mm banana socket to a strong nickel-plated crocodile clip. The Amass 22.580.100 is built for dependable bench and field testing. It features a silicone jacket for excellent flexibility and a 15 A current rating for higher-demand tasks.
Features
- 4 mm stackable banana plug → 55 mm nickel-plated crocodile clip
- 1 m length
- Silicone-insulated 0.75 mm² cable for durability and tangle-free use
- Rated 30 Vac / 60 Vdc max at 15 A
- Colour-coded red or black versions for easy polarity tracking
- Stackable banana plug accepts additional leads for parallel connection
Specifications
| Parameter |
Details |
| Connector A |
4 mm stackable banana plug (red or black) |
| Connector B |
55 mm nickel-plated crocodile clip |
| Cable length |
1.0 m |
| Conductor size |
0.75 mm² |
| Insulation |
Silicone (SIL) |
| Rated voltage |
30 Vac / 60 Vdc max |
| Rated current |
15 A |
| Contact material |
Nickel-plated brass |
| Colour options |
Red / Black |
| Manufacturer |
Amass |
